Case|CHIEFTEC|Pro mini|MidiTower|MicroATX|MiniITX|Colour Black|AZ-01B-OP
The CHIEFTEC Pro Mini presents a modern m-ATX mini tower PC case with a timelessly elegant, brushed front panel, complemented by an interior designed with a modern layout for optimal hardware and cooling compatibility. The CHIEFTEC Pro Mini features added sound-absorbing material on the side and front panels to provide an optimized noise level, while a total of 8 possible fan mounts provides flexible cooling configurations. The Pro Mini is ready to deliver customers an ideal combination of performance, noise and quality design.
- Elegant & modern design
- Sound-absorbing material
- 1x 120mm PWM fan pre-installed
Charakteristikos
- Garantija
- 24
- Summary
- Chieftec AZ-01B-OP. Form factor: Mini Tower, Type: PC, Product colour: Black. Front fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm. Supported HDD sizes: 2.5,3.5". Width: 212 mm, Depth: 360 mm, H
- Vendor Homepage
- https://www.chieftec.eu/products-detail/587/AZ-01B-OP
- Category Code
- CAS
- Unit Box Height
- 0.48
- Unit Box Length
- 0.48
- Unit Box Width
- 0.275
- Design (Form factor)
- Mini Tower
- Design (Product colour)
- Black
- Weight & dimensions (Depth)
- 360 mm
- Weight & dimensions (Height)
- 420 mm
- Weight & dimensions (Weight)
- 5150 g
- Weight & dimensions (Width)
- 212 mm
- Model
- AZ-01B-OP
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.06336 cubm
- Unit Calculated Weight
- 5.9 kg
- Model name
- Pro mini
- Ports & interfaces (USB Type-C ports quantity)
- 1
- Ports & interfaces (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity)
- 1
- Ports & interfaces (USB 2.0 ports quantity)
- 1
- Design (Number of 2.5" bays)
- 2
- Design (Number of 3.5" bays)
- 1
- Design (Number of internal 3.5" bays)
- 1
- Design (Supported motherboard form factors)
- micro ATX/Mini-ITX/uATX
- Power supply (Power supply included)
- No
- Ports & interfaces (Audio input)
- Yes
- Ports & interfaces (Audio output)
- Yes
- Ports & interfaces (USB 3.0)
- 1
- Packaging data (Package weight)
- 6000 g
- Design (Anti-dust filter)
- Yes
- Design (Tempered glass panel(s))
- No
- Cooling (Front fans diameters supported)
- 120/140 mm
- Cooling (Rear fans diameters supported)
- 120 mm
- Cooling (Top fans diameters supported)
- 120/140 mm
- Design (Illumination)
- No
- Design (On/off button)
- Yes
- Design (Reset button)
- Yes
- Design (Side window)
- No
- Design (Type)
- PC
- Cooling (Front radiator sizes supported)
- 240/280/360 mm
- Cooling (Number of front fans supported (max))
- 3
- Cooling (Number of rear fans supported (max))
- 1
- Cooling (Number of top fans supported (max))
- 2
- Cooling (Rear fans installed)
- 1x 120 mm
- Cooling (Top radiator sizes supported)
- 240/280 mm
- Storage (Supported HDD sizes)
- 2.5/3.5 "
- Design (Maximum CPU cooler height)
- 165 mm
- Design (Maximum graphics card length)
- 330 mm
- Design (Maximum PSU length)
- 180 mm
- Design (Number of expansion slots)
- 4
- Design (Number of storage drives supported)
- 3
- Cooling (Liquid cooling capability)
- Yes
- Weight & dimensions (Material thickness)
- 0.6 mm
- Design (Full-Height expansion slots)
- 4
